Đồng hồ đo độ dày Peacock, dial thickness gauge Đồng hồ đo độ dày Peacock, dial thickness gauge

MÔ TẢ SẢN PHẨM



https://youtu.be/ffJUFIfZQS0

https://youtu.be/zmg13uEEhBk

https://peacockvn.blogspot.com/2016/08/dung-cu-o-peacock.html

These thickness gauges are especially handy for measuring thickness of small parts, metal,
 rubber, vinyl, paper, foil and other sheet material.



The objects to be measured is clamped by simple lever operation.
The measured values are read directly on the dial gauge.



Since the anvil and the contact point are adjusted for parallelism, accurate measured values
are obtained.

Dial Thickness Gauges 0.01mm type

Model

G

Graduation

0.01mm

Range

0 - 10mm

Ø10mm flat contact point and
  anvil (ceramic)



G

Model

G-1A

Graduation

0.01mm

Range

0 - 10mm

Ø5mm flat contact point and
  anvil (metal)



G-1A

Model

G-1M

Graduation

0.01mm

Range

0- 10mm

Ø6mm flat contact point and
  anvil (metal)
The frame on the anvil side
  is cut, which facilitates
  measurement in a narrow place.
G-1M

Model

G-2

Graduation

0.01mm

Range

0 - 20mm

Ø10mm flat contact point and
  anvil (ceramic)

G-2

Model

G-3

Graduation

0.01mm

Range

30mm (Anvil 20mm)

Ø10mm flat contact point and
  anvil (ceramic)
Anvil side is adjustable
G-3

Model

G-4

Graduation

0.01mm

Range

65mm (Anvil 55mm)

Spherical contact point
Anvil side is adjustable

G-4

Model

H

Graduation

0.01mm

Range

0 - 10mm

Ø10mm flat contact point and anvil (ceramic)
H

Model

H-1A

Graduation

0.01mm

Range

0 - 10mm

Ø5mm flat contact point and anvil (metal)
H-1A

Model

H-2

Graduation

0.01mm

Range

0 - 10mm

Spherical contact point and anvil
H-2



Model

H-3

Graduation

0.01mm

Range

0 - 10mm

Spherical contact point and roller type anvil
H-3
G CÔNG CỤ,DỤNG CỤ,MÁY MÓC CẦM TAY Số lượng: 0 Sản phẩm

  •
